Ultrasonic Wind Sensor (UWS-200)
The Ultrasonic Anemoneter is designed a compact automatic sensor without moving parts. Anemometer measures
Wind speed and wind direction.
THe Ultrasoninc Anemometer is very caccurate, responds rapidl to wind changes, and has zero starting threshold.
The Anemometer is not affected by extreme climatic conditions. Thd Ultrasonic Anemometer can be used in con-
junction with a PC, Data Logger or other device, provided it is compatible with the RS422 output.
|
SPECIFICATION
|
|
| Measuring range | |
|
Wind Speed
|
0 ~ 75m/s |
|
Wind direction
|
0 ~ 360¢ª |
| Accuracy | |
|
Wind Speed
|
¡¾3% |
|
Wind direction
|
¡¾3¢ª |
|
Temperature
|
-40 ~ 70¡É |
|
Data Output
|
RS422/RS232 |
|
Power source
|
24VDC ¡¾20%, max. 4A |
|
Protection
|
IP66 |
|
Weight
|
approx. 2.5kg
|
